Sliding Hinge Fridge Freezers Guide

Sliding (cam-rise) hinges are generally better for commercial walk-in coolers and freezers. They self-close, reduce gasket wear on uneven floors, and lift the door during opening to prevent dragging. Fixed hinges are simpler but lack these features. For high-traffic food service environments, sliding hinges offer superior longevity and energy efficiency.

Yes, in most cases a fixed hinge can be replaced with a sliding cam-rise hinge such as the Kason 1245 Series, provided the door dimensions and offset measurements are compatible. The Kason 1245 is drilled and countersunk for standard 1/4" flat head screws, making retrofitting relatively straightforward. Always verify the offset measurement and load rating before replacing.

A cam-rise hinge uses a specially shaped cam profile to lift the door as it swings open. This lifting action allows the door to clear the floor, minimizing gasket contact and wear. When released, the cam profile guides the door back to a fully closed, sealed position automatically, reducing energy loss in refrigerated environments.

Yes. The Kason 1245 Series cam-rise hinge features a reversible design that allows simple manual adjustment to accommodate either right- or left-hand door swing. No special tools or disassembly of the hinge are required, making it a versatile solution for walk-in cooler and freezer installations with varying door configurations.

The Kason 1245 Series hinge is constructed from high-pressure die-cast zinc with a self-lubricating nylon cam. This combination provides excellent strength and corrosion resistance in cold, humid environments. Powder-coated finishes are also available for severe applications. These materials ensure long-term, trouble-free operation in commercial refrigeration settings.

Check the hinge offset measurement — the Kason 1245 Series features a 1-5/8" offset — and confirm it matches your door frame. Also verify the load rating using the manufacturer's Hinge Selector (Group D for the 1245 Series). The doors lift off without disassembly, making it easier to measure and compare before purchasing a replacement.
